List of major laboratories and facilities available in the department
|
Name of The Facility |
Brief Description |
|
High Voltage & Power System Laboratory |
Digital Relays, Fault Locaters, Cable Fault Tester Hi Pot Test, High Voltage Spark Tester, High Voltage Testing equipment |
|
Power Electronics & Electric Drives Laboratory |
Power Electronics laboratory provides facilities to evaluate the steady-state/dynamic performance of static switches. Test setups are available to analyze the performance of single phase and three-phase line commutated converters using gate firing circuits based on UJT, TCA-785 (IC) and microprocessor under various loads. Experiment kits are available for switching-aid circuits, AC voltage controllers, forced commutation circuits of SCR, Choppers, Inverters and switching regulators. The laboratory is also equipped with advanced digital-controller both for experimentation and research work for Chopper and rectifier based DC Motor drive, Permanent Magnet Synchronous motor drive, Permanent Magnet brush-less DC motor drive, Induction motor drive, and Switch Reluctance motor drive. Experimental facilities are developed in the field of power quality improvements, solar water pumping system, photovoltaic supply system etc. 15kW and 4 kW solar array simulator facilities and 1.2KW capacity rooftop installed Photovoltaic panels are available in the laboratory for facilitating various experiments. Many Digital Oscilloscopes (DSO) such as four channel 300 MHz DSO and 200MHz mixed signals DSOs, power quality analyzers for three-phase and single phase are available in the laboratory. |
|
Electric Machines Laboratory |
Most of electrical machines and transformers are available for experimentation such as DC machines, Single Phase Induction Motors, Three Phase squirrel Cage and Slip-ring Induction Motors, Wound field cylindrical rotor synchronous machines, Salient pole rotor synchronous machines, Single Phase & Three Phase Transformers etc. |
|
Control Systems Laboratory |
Modern control kits like PID Simulator and System Simulators. Virtual Control Laboratory System for combinational experiments in the area of computer controlled servomotors. Experiments for computer simulated systems based on MATLAB software. Function Generator Sine, Square and Triangle waveforms, Digital storage oscilloscope, Power Function Generator: Sine, Square. |
|
Electrical Measurement & Instrumentation Laboratory |
All measuring instruments and bridges. Megger, Energy Meter, Calibration kits for Ammeter and voltmeter, Transducer kits. |
|
Microprocessor and Embedded System Laboratory |
8085 Microprocessor kits, 8086 Microprocessor kits, Stepper motor kits, Function Generator-3 MHz, Digital multimeter, Micro-controller 8051 kits, DSP kits with TMS6713 processor. ARM Evolution boards with ARM9 and ARM7 processors. This lab is actively used for the development of industrial automation solutions, embedded system design and domestic applications. Some of outcome of this lab are Smart Traffic Light Controllers, Non-Invasive Optical Sensing system and Model for Parameter Estimation of Human Skin, Wireless application in the agriculture and many more. It is the platform in the department to exercise the emerging technologies like GSM/GPRS/GPS, Arduino embedded boards, Android applications development etc. Recently lab is equipped with Raspberry PI, MSP430 Lunchbox kit etc to enhance the capabilities in the domain of IoT and industry 4.0. |
|
High Performance Computing Laboratory |
In this lab the high performance computing platform is consisting Xeon. Quad Core servers equipped with Kepler and Fermi GPUs. The equipment costing around 5.5Lakh was donated by IIT Delhi, New Delhi. |
|
Electrical Network Laboratory |
This lab is equiped with major experiments of Electrical Network domain used by most of the departments of the institute, like Computer Engg, Electronics and Telcommunication Engg, Biomedical Engg.. etc |
|
Hybrid Energy System Laboratory |
The department is in process of establishing Hybrid energy system lab. |
|
Faults and System Protection Laboratory |
This lab is equipped with experimental setup of Lightening arrester, Air Break Switches, drop out Switches, Insulators. This lab also equipped with synchronous alternators, and three phase transformers to understand and detection of faults using different method like positive, negative and zero sequence reactance. Illustration of various types relays like Differential Relays, Mho relay, Inverse definite minimum time relays to understand it's features and working characteristics. |
|
PG Research Lab |
The lab is specially designed for PG students to provide an environment for their R&D activities. The lab is equipped with modern test bench, LCD projector, computational facilities, power supplies, electrical drives, DSOs etc. |
|
CIDI |
facilities for product development are available in this centre for the developing student projects and starts up. The centre works in collaboration with many industries and entrepreneurs on solving field problems. The centre is equipped with facilities such as PCB drilling & cutting tool, X – Y Plotter, Bench Grinding Machine, PCB Designing System, PCB Prototype Machine, 3D Printer, embedded system development tool and high performance computational systems etc. |
List of software available
| Name of software | Runs on | Open source |
| MI-Power Tool (Simulation tool) | Server | No |
| MATLAB (Simulation tool) | Server | No |
| NI Labview (Simulation tool) | Server | No |
| Turnitin (Plagiarism detection ) | Machine | No |
| Libre office (Office tool) | Machine | Yes |
| MS Office (Office tool) | Machine | No |
| Windows 8,10 (Operating System) 32bit/64bit, Desktop | Machine | No |
| Ubuntu 12.04, 14.04, 16.01 (Operating System) 32bit/64bit, Desktop and Server | Machine | Yes |
| Inkscape (Graphics tool) | Department Server | Yes |
| GNUPlot (Graphs plot tool) | Department Server | Yes |
| Kile (Latex) | Department Server | Yes |
| Kiel (Embedded application IDE) | Machine | No |
| Sci Lab (Simulation tool) | Department Server | Yes |
